100 ton Lifting Capacity Cylinder Luffing Marine Cranes for Efficient Loading and Unloading of Containers and Bulk Cargo

Short Description:

1. The MAXTECH MS series consists of versatile cylinder – luffing marine cranes, suitable for container handling and/or general cargo loading and unloading.

2. The MS marine crane, in particular, has a lifting capacity of up to 100 tonnes and can handle various items, ranging from dry bulk, general cargo to containers.

3. This series of cranes is characterized by its low self – weight and building height.

4. Thanks to the rational position of the boom pivot point, the loading space can be utilized to the maximum extent. Meanwhile, the low – center – of – gravity design helps ensure the stability of the vessel and increases its cargo – carrying capacity.

Send email to us Download File

Product Detail

Enquiry

Product Tags

Application

The MS series marine cranes are widely used in various ship operation scenarios, especially on multi - purpose ships and container ships. During port loading and unloading operations, they can efficiently complete the loading and unloading of containers and the handling of general cargo, effectively improving port operation efficiency. During sea transportation, they can meet the demands of cargo lifting and placement at any time, ensuring the safe transportation of goods.

Model

The MS series includes various models to meet different operational requirements. The MS marine crane, for example, is a typical representative. With its 100 - tonne lifting capacity, it plays a significant role in handling various types of goods. Different models vary in parameters such as lifting capacity and working radius, allowing users to select according to the actual ship type and cargo handling requirements.

Product rage:

Crane type	MS 40	MS 60	MS 80	MS 100
Max. capacity	40t	60t	80t	1oot
Outreach (max.)	30m	32m	38m	43m
Total weight (appr.)	40t	45t	70t	80t

Feature

1. Compact Design: The overall design is compact, occupying minimal space on the ship. This not only creates more room for cargo transportation but also has a positive impact on the ship's structure, ensuring its structural stability.
2. Safe and Reliable: It has good stability. The low - center - of - gravity design reduces the risk of ship swaying during operation, ensuring the safety of operators and cargo. The crane can resist the erosion of saltwater, wind, sunlight, dust, and vibration in the long - term, guaranteeing stable operation in harsh environments.
3. Easy Maintenance: The rational design of the structure makes all components easy to inspect and maintain, reducing maintenance costs and downtime and improving the equipment's operating efficiency.
4. Optimal Viewing Angle: The low - height design provides operators with a broader view. It is convenient for operators to clearly observe the cargo lifting situation during operation, enabling precise control and enhancing operation safety and efficiency.
5. High - performance Winch: Equipped with a high - performance winch designed for continuous operation, it can ensure reliable and rapid material handling, meeting the needs of high - intensity cargo loading and unloading.
