Electric & Hydraulic Foldable Boom: Ship Deck Crane with 30T @ 5m and 20T @ 15m Lifting Specifications
MAXTECH electric & hydraulic foldable boom ship deck cranes are the go - to for marine, offshore, and wind industries. Ideal for diverse lifting tasks, they shine in equipment handling, combining strength with flexibility.
Their compact build fits vessels of all sizes, even in tight spaces. The secret lies in the low weight - to - performance ratio, allowing outreaches from short to 15 - meter extensions.
Tailored to unique work environments, these cranes come with extra features. The 30T @ 5m & 20T @ 15m ship deck crane, with its electric - hydraulic foldable boom, offers efficient and precise operation. A perfect blend of power and versatility.
The 30T @ 5m & 20T @ 15m ship deck crane technical parameter:
| 1) | Safety Working load | 30t@5m & 20t @15m |
| Work Radius: ( Max) | 15m | |
| (Min ) | 5 m | |
| Steel wire length | 200m zinc | |
| Hoisting speed（full load） | 0～16m/min | |
| Rotating speed | 0 0.6r/min | |
| Slewing angle | ≤360° | |
| Average Luffing Time | ~ 90s |
| 2) | El-motor | |
| Power | ~ 132 KW （to be confirmed） | |
| El-duty |
| 3) | Working duty | S1 | |
| Insulation class | F | ||
| Protection type: | IP55 | ||
| Explode-proof: | Exd ⅡBT4 | N/A | |
| Motor space heater | Without ¨ | With | |
| Motor starting method: | Direct ¨ | Star-delta | |
Wireless remote control
nameplate
